NX603 High Pressure Hose
NX603

NX603 High Pressure Hose

1/2" (DN12) - 1 1/4" (DN32)

The NX603 is a very strong and light sewer cleaning hose. A plastic sewer hose can save a lot of energy due to the lower flow resistance than with rubber hoses. The weight of the hose also plays a major role in this.

Contact PRO-JETTING now and ask about the affordable offer.

NX603 High Pressure Hose

1/2" (DN12) - 1 1/4" (DN32)

The NX603 is a very strong and light sewer cleaning hose. A plastic sewer hose can save a lot of energy due to the lower flow resistance than with rubber hoses. The weight of the hose also plays a major role in this.

Specifications

Core: thermoplastisch elastomer
Strengthening: Synthetic and aramid fiber
Surface: Polyurethane
Temperature: 40°C to +60°C

Features

  • Light weight
  • Smooth surface
  • Low flow resistance

Specifications

Core: thermoplastisch elastomer
Strengthening: Synthetic and aramid fiber
Surface: Polyurethane
Temperature: 40°C to +60°C

Features

  • Light weight
  • Smooth surface
  • Low flow resistance

NX603

code DN I.D. O.D. W.P. B.P. buig radius
NX603-8 12 1/2" 23mm 280bar 840bar 100mm
NX603-12 20 3/4" 29mm 250bar 625bar 125mm
NX603-16 25 1" 38mm 250bar 625bar 150mm
NX603-32 32 1 1/4" 46mm 250bar 625bar 250mm
