PRO Zero Thrust Cavitation Cleaning Gun

PRO Zero Thrust Cavitation Cleaning Gun

CW550 - max. 560 bar (8,122psi)

The CW550 PRO Zero Thrust Cavitation Cleaning Gun is used according IMCA guidelines for large offshore cavitation cleaning operations to remove coatings and thick marine growth from ship hulls, propellers, thrusters, rudders, pillars, pipelines, piers, risers and walls. The CW550 is safe and ergonomic to use with a long zero thrust lance to neutralize the reaction force of the cavitation blast and avoid diver fatigue.



We are happy to assist you in finding the cavitation cleaning equipment that best fits your application, contact DiveWise now!

 Download Brochure

PRO Zero Thrust Cavitation Cleaning Gun

CW550 - max. 560 bar (8,122psi)

The CW550 is used according IMCA guidelines for large offshore cavitation cleaning operations to remove coatings and thick marine growth from ship hulls, propellers, piers, walls and other structures. The CW550 is safe and ergonomic to use.

CW550

Specifications

Minimum pressure: 120 bar (1,740 psi)
Maximum pressure: 560 bar (8,122 psi)
Minimum flow: 28 LPM (7.5 GPM)
Maximum flow: 80 LPM (21 GPM)
Lance length: 750mm (29.5”)
Zero thrust lance length: 1000 mm (39.4”)
Weight: 2800g (6.2lbs)
Weight under water: 1600g (3.5lbs)
According: IMCA guidelines
Certified: SIR
Compatible with: HDE235_99, HDMD235_99, HDE440_96, HDMD410_96

Features

  • Improved cavitation technique
  • Zero thrust lance to neutralize reaction force
  • Intensity adjustable with high-pressure unit
  • Durable, salt water resistant materials
  • Double-walled stainless steel lance
  • Tapered lance tip with visible cover ring
  • Ergonomic controls
  • Large control lever with “Safety catch”
  • Swiveling connection
  • Use with single neutrally buoyant high-pressure hose

Specifications

Minimum pressure: 120 bar (1,740 psi)
Maximum pressure: 560 bar (8,122 psi)
Minimum flow: 28 LPM (7.5 GPM)
Maximum flow: 80 LPM (21 GPM)
Lance length: 750mm (29.5”)
Zero thrust lance length: 1000 mm (39.4”)
Weight: 2800g (6.2lbs)
Weight under water: 1600g (3.5lbs)
According: IMCA guidelines
Certified: SIR
Compatible with: HDE235_99, HDMD235_99, HDE440_96, HDMD410_96

Features

  • Improved cavitation technique
  • Zero thrust lance to neutralize reaction force
  • Intensity adjustable with high-pressure unit
  • Durable, salt water resistant materials
  • Double-walled stainless steel lance
  • Tapered lance tip with visible cover ring
  • Ergonomic controls
  • Large control lever with “Safety catch”
  • Swiveling connection
  • Use with single neutrally buoyant high-pressure hose
